Description
The Hirose DF3 Series Straight Through-Hole PCB Header is designed to provide reliable and precise wire-to-board or board-to-board connections in compact electronic assemblies. Featuring 5 contacts in a single-row configuration with a 2.0mm pitch, this header delivers stable electrical performance while optimizing PCB space usage.
Built with a shrouded housing, the DF3 series header ensures accurate alignment during mating, protects the contacts from damage, and reduces the risk of incorrect insertion. Engineered to meet Hirose’s high quality standards, this connector offers excellent durability and consistent performance, making it suitable for a wide range of electronic applications.
Key Features & Benefits:
-
Compact 2.0mm Pitch Design
Provides reliable connectivity while minimizing board space, ideal for high-density and compact PCB layouts. -
5-Way Single Row Configuration
Features 5 contacts in one row, suitable for signal and low-power connections in electronic devices. -
Straight Through-Hole Mounting
Designed for through-hole PCB mounting, offering strong mechanical retention and reliable solder joints. -
Shrouded Header for Secure Mating
The shrouded design ensures proper alignment, protects contacts, and reduces the risk of damage or misalignment during connection. -
Durable & Reliable Performance
Manufactured by Hirose to meet strict quality and performance standards, ensuring long service life and stable electrical connections.
Applications:
-
Consumer electronics
-
Industrial and automation equipment
-
Communication devices
-
Compact electronic assemblies
-
PCB interconnections
Specifications:
-
Series: Hirose DF3
-
Connector Type: PCB Header
-
Mounting Style: Through-Hole
-
Orientation: Straight
-
Pitch: 2.0mm
-
Number of Contacts: 5
-
Rows: Single Row
The Hirose DF3 Series 5-way Straight PCB Header is an excellent choice for designers and technicians seeking compact size, reliable performance, and secure PCB connectivity in electronic systems.
